| PRODUCT PERFORMANCE | ||||
 | ||||
| Rated Voltage | 3.7V | 5V | 12V | 24V |
| Rated Current | 500mA | 360mA | 100mA | 160mA |
| Resistance(Ω) | 10~150Ω | |||
| Exhaust time | 400mmHg 100CC tank, exhaust <3S | |||
| Use fluids | Air、Water | |||
| Airtightness | 400mmHg 100CC tank, leakage <3mmHg/MIN | |||
| Life test | 500H (1.7s on , 0.8s off) | |||
| Weight | 16g | |||
| principal application | Blood pressure monitor, breast pump deflation valve | |||
