| PRODUCT PERFORMANCE | ||
 | ||
| Rated Voltage | 6V | 24V |
| Rated Current | 850mA | 520mA |
| Resistance(Ω) | 7~23Ω | |
| Exhaust time | 400mmHg 100CC tank, exhaust <3S | |
| Use fluids | Air、water | |
| Airtightness | 400mmHg 100CC tank, leakage <3mmHg/MIN | |
| Life test | 500H (1.7s on , 0.8s off) | |
| Weight | 38g | |
| principal application | Micro water valve for water dispenser | |
