The KYK1140APM is a micro air pump designed for high-performance applications, powered by a high-torque 1140-series DC motor to deliver superior power output and exceptional stability under high-load, long-duration operating conditions. Its reinforced carbon brush system and optimized magnetic circuit contribute to a significantly extended service life, meeting the demanding durability requirements of industrial and commercial-grade equipment.
The pump's design emphasizes high-pressure output and stable flow, achieved through a precision-optimized air path and a body constructed from high-strength engineering materials. Despite its power, it operates with low noise and minimal vibration, thanks to internal vibration damping and chamber noise reduction. This ensures a smooth and quiet user experience, making it a trusted choice for medical auxiliary devices, high-end beauty instruments, industrial analyzers, and commercial booster systems.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated voltage | DC12.0V | DC24.0V |
| Rated current | <2.2A | <1.5A |
| Air flow | >20L/min | |
| vacuum | <-600mmHg | |
| Airtightness | <3mmHg/min from 300mmHg at500CC tank | |
| Noise | <80dB | |
| Life test | 500 Hours | |
