| PRODUCT PERFORMANCE | ||
 | ||
| Rated Voltage | 12V | 24V |
| Rated Current | 2200mA | 1100mA |
| Resistance(Ω) | 5.5Ω | 11Ω |
| Displacement | 3.5mm | |
| Thrust | 5N | |
| Insulation leve | F | |
| Life test | 1 million times(7s on , 3s off) | |
| Weight | g | |
| principal application | Micro diaphragm pump for water dispenser, tea bar machine | |
