The KYK12VPM Micro Diaphragm Pump is tailor-made for personal health and care devices that require a sophisticated design and a silent user experience. At its core is a high-efficiency 130 micro motor, achieving an optimal balance between power, size, and energy consumption.
The pump’s compact structure and stable output deliver a continuous, gentle airflow perfect for beauty instruments (like handheld oxygen injectors and nano-sprayers) and desktop/portable nebulizers. Its key advantages are exceptionally low-noise and low-vibration operation, which enhances the premium feel of the end product while ensuring a comfortable user experience. Furthermore, the efficient motor design lowers overall power consumption, making it an ideal choice for battery-powered portable devices to extend their operational life.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated Voltage | 3.0V | 5.0V |
| Rated Current | 250mA | 150mA |
| Air Flow | 1.0~1.2L/min | |
| Pressure | ＞300mmHg | |
| Leakage | <3mmHg/min from 300mmHg at 100CC tank | |
| Noise | ＜62dB(30 cm away) | |
| Life test | 500H (10s on , 7s off) | |
| Weight | 15g | |
| principal application | Small massager, low noise micro air pump, air pump | |
