The KYK28APM is a high-performance micro air pump for lightweight equipment, featuring a high-efficiency 280-series DC motor for stable, low-energy operation and a faster response time. Its lightweight, compact design simplifies OEM integration while delivering a robust flow rate for pressurization, suction, and circulation.
Supporting both positive and negative pressure modes, the pump uses a reinforced, wear-resistant diaphragm for durability. Full customization of pressure, flow, and connectors makes it ideal for international trade. It is a favored choice for portable air samplers, micro-aerators, small medical auxiliary devices, and inflation systems.
PRODUCT PERFORMANCE | |||
| |||
Rated Voltage | DC5.0V | DC6.0V | DC12.0V |
Rated Current | <650mA | <550mA | <300mA |
Air Flow | >4L/min | ||
Pressure | >-480mmHg | ||
Airtightness | <3mmHg/min from300mmHg at500CC tank | ||
Noise | ＜65dB(30CM away) | ||
Life test | >300 Times | ||
Weight | ≈100g | ||
