The KYK31CPM is a high-performance micro air pump designed for lightweight equipment, powered by a 310-series high-efficiency DC motor for robust and stable power output. An optimized magnetic circuit reduces energy consumption while increasing rotational speed, ensuring reliable performance in high-frequency work scenarios.
The pump excels in pneumatic performance, delivering rapid pressure buildup and a smooth, continuous flow for both pressurization and suction. This is achieved through an enlarged air chamber and an optimized air path. Durability is equally central to its design, incorporating a wear-resistant diaphragm and a reinforced bearing system to ensure a significantly extended service life. Its compact, low-noise profile allows for seamless integration into products like beauty and massage devices, air quality monitors, and smart home systems.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated voltage | DC12.0V | DC24.0V |
| Rated current | <500mA | <400mA |
| Air flow | >2.5L/min | |
| Max vacuum | >-450mmHg | |
| Airtifhtness | <3mmHg/min from 300mmHg at500CC tank | |
| Noise | <60dB | |
| Life test | 500 Hours | |
