The KYK50BPM Micro Air Pump, powered by a high-efficiency 500-class motor, delivers strong torque, a long lifespan, and stable pressure for continuous high-load use. Its reinforced chamber ensures efficient airflow, while the optimized low-noise design makes it ideal for home and personal care. Perfect for OEM/ODM projects, its compact body supports versatile mounting and full parameter customization. A trusted component in global markets, it is widely used in pneumatic massagers, portable booster equipment, and vacuum-assisted tools.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated Voltage | 12V | 24V |
| Rated Current | 1000mA | 500mA |
| Air Flow | ＞8.0L/min | |
| Pressure | ＞800mmHg | |
| Negative Pressure | ＜-500mmHg | |
| Leakage | <3mmHg/min from 300mmHg at 100CC tank | |
| Noise | ＜68dB(30 cm away) | |
| Life test | 500H (10s on , 7s off) | |
| Weight | 115g | |
| principal application | Fixed bracket beauty instrument micro diaphragm pump | |
