The KYK50DPMD Micro Air Pump delivers robust power output, a durable structure, and stable airflow, making it a preferred core component for bulk procurement. Its compact design integrates seamlessly into beauty instruments, pneumatic equipment, small home appliances, and portable inflation/suction devices, enhancing overall device performance and lifespan. The KYK50DPMD is supplied factory-direct for maximum cost-effectiveness, earning the trust of OEM/ODM clients in Europe, the Middle East, and Southeast Asia. Known for its durable motor and superior airtight structure, it supports full parameter customization and provides key advantages like low noise, a long service life, and stable performance, making it the ideal choice for manufacturers seeking high-quality, reliable power.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated Voltage | 12V | 24V |
| Rated Current | 1000mA | 500mA |
| Air Flow | ＞8.0L/min | |
| Pressure | ＞800mmHg | |
| Negative Pressure | ＜-500mmHg | |
| Leakage | <3mmHg/min from 300mmHg at 100CC tank | |
| Noise | ＜68dB(30 cm away) | |
| Life test | 500H (10s on , 7s off) | |
| Weight | 115g | |
| principal application | Vacuum diaphragm pump, beauty instrument air pump | |
