The KYK50EPM provides a powerful and reliable core power solution, engineered for manufacturers of high-performance beauty and personal wellness equipment. At its heart is a 545 DC motor, renowned for its high torque output and stable low-speed performance. This provides a robust, smooth, and continuous power foundation, ensuring treatment processes are both effective and consistent. Through an optimized diaphragm structure and precision engineering, the pump is designed for low-vibration and low-noise operation, directly imparting a sense of quiet, premium quality to your end product. Recognizing that safety and reliability are paramount for devices with direct human contact, the KYK50EPM is designed with a medical-grade philosophy and engineered to maintain consistent performance over its extended lifespan, serving as the trustworthy 'heart' of your product.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated Voltage | 12V | 24V |
| Rated Current | 1000mA | 500mA |
| Air Flow | ＞8.0L/min | |
| Pressure | ＞800mmHg | |
| Negative Pressure | ＜-500mmHg | |
| Leakage | <3mmHg/min from 300mmHg at 100CC tank | |
| Noise | ＜68dB(30 cm away) | |
| Life test | 500H (10s on , 7s off) | |
| Weight | 115g | |
| principal application | Micro air pump wall breaking machine vacuum pump | |
