The KYK27HPM delivers robust performance (1.8–3.5L/min flow, 120kPa pressure) utilizing a proven 370 motor. As an evolution of the KYK27APM, this pump is optimized for stability and ease of assembly. It incorporates a barbed fitting to prevent tube detachment and a built-in bracket structure for secure device mounting. Its mature design ensures seamless compatibility with a wide range of portable electronics and home appliances.
PRODUCT PERFORMANCE | ||||
| ||||
Rated Voltage | DC3.7V | DC6.0V | DC12.0V | DC24.0V |
Rated Current | <600mA | <450mA | <300mA | <150mA |
Air Flow | 1-3L/min | |||
Pressure | >600mmHg | |||
Airtightness | <3mmHg/min from300mmHg at500CC tank | |||
Noise | ＜62dB(30CM away) | |||
Life test | 300 Hours | |||
Weight | 60g | |||
