The KYK31HPM is a high-performance micro air pump for lightweight equipment, featuring an upgraded H-class structural design. Its more scientific internal air path and high-strength engineering material body provide exceptional wear resistance and sealing, which minimizes airflow loss and enhances stability. A reinforced diaphragm and an integrated vibration-damping support structure ensure the pump remains smooth and durable even during high-frequency operation.
The pump's design philosophy centers on three core principles: compact, lightweight, and durable. An optimized rotor system and flow guide structure achieve a higher power density within a small footprint, meeting the assembly needs of space-constrained devices. Furthermore, its modular design facilitates secondary development for OEM clients, allowing for flexible application expansion. The result is a quiet, low-vibration component that delivers a smooth output, making it ideal for beauty and portable therapy devices, air samplers, and smart home micro-pressure systems.
| PRODUCT PERFORMANCE | ||
 | ||
| Rated voltage | DC12.0V | DC24.0V |
| Rated current | <1.2A | <1.1A |
| Air flow | >6L/min | |
| Max vacuum | >500mmHg | |
| Airtightness | <3mmHg/min from 300mmHg at500CC tank | |
| Noise | <80dB | |
| Life test | 500 Hours | |
